24V 8.6W R W G B IC Components Machine Vision Ring Light

Brand Name : OPT

Model Number : OPT-RIB15000

Place of Origin : China

MOQ : 1 piece

Price : Negotiable

Payment Terms : T/T

Supply Ability : Negotiable

Delivery Time : 7 days at the soonest

Packaging Details : Craft Box

Model : OPT-RIB15000

Angle : 0°

Color : Blue/Green/Red/White/

Channels : 1

Output : W: 24V/10.8W R: 24V/8.6W B: 24V/10.8W G: 24V/8.6W

Housing Size（Diameter） : 150

Recommended Controller : OPT DPA2024E

Contact Now

24V/8.6W R/W/G/B Machine Vision Ring Light OPT RIB Series For IC Components Inspection OPT-RIB15000

Product Features

◆ RIB Series OPT-RIB15000 ring light with good directivity and ideal for long working distance illumination applications

◆ OPT-RIB15000 ring lights have lower power consumption compared with OPT RI Series.

◆ The OPT-RIB15000 ring lights sources have 1 channel and 4 colors; the light source output in red color is 24V/8.6W; the output of green light source is 24V/8.6W; the output of blue light source is 24V/10.8W; the output of white light source is 24V/10.8W.

◆ The housing size in diameter of the OPT-RIB15000 ring lights is 150mm.

◆ The emitting angle of the OPT-RIB15000 ring lights is 0°.

◆ The light source OPT-RIB15000 can be used to many kind of applications such as electronic components inspection , PCB inspection, IC components inspection and plastic containers inspection.

◆ OPT-RIB15000 ring lights are customizable in color, size, mounting type and emitting angle.

Application Cases
◆ PCB inspection

◆ Electronic components inspection

◆ Components inspection of IC

◆ Plastic containers inspection

Specifications

Model	OPT RIB15000
Color	Red/Blue/Green/White
Angle	0
Output	W: 24V/10.8W R: 24V/8.6W B: 24V/10.8W G: 24V/8.6W
Channels	1
Housing Size(Diameter)	150mm
Recommended Controller	DPA2024E
Emitting Angle	0°

Product Details:

24V 8.6W R W G B IC Components Machine Vision Ring Light

Applicaitons: Motor accessories inspection

24V 8.6W R W G B IC Components Machine Vision Ring Light
